Structured logging is a practice where you apply the same message format to all of your application logs. The end result is that all your logs will have a similar structure, allowing them to be easily searched and analyzed.

Serilog is a popular logging library in .NET, packed with many features. It provides logging to files, logging to the console, and elsewhere.

However, Serilog is unique because it comes with support for structured logging out of the box.

Let's see how we can install Serilog and configure it an ASP.NET Core application.

Installing Serilog

To install Serilog in ASP.NET Core you can add the following NuGet package:

Install-Package Serilog.AspNetCore

This NuGet packages comes with a simple API to integrate Serilog into your application. You can call the UseSerilog method on the HostBuilder instance to provide a lambda method to configure Serilog.

I think the most flexible way to configure Serilog is through application settings, which is achieved by calling ReadFrom.Configuration().

You can also call the UseSerilogRequestLogging() method to introduce automatic HTTP request logging in your API.

var builder = WebApplication.CreateBuilder(args);

builder.Host.UseSerilog((context, configuration) =>
    configuration.ReadFrom.Configuration(context.Configuration));

var app = builder.Build();

app.UseSerilogRequestLogging();

app.Run();

The next question is how do you provide the actual configuration values to Serilog?

Configuring Serilog With appsettings.json

You need to add a Serilog section in your appsettings.json file.

Here you can configure, among other things:

  • Which sinks to use with Serilog
  • Override default and minimum log levels
  • Configure file logging arguments

In this example, we're adding the Console and File sinks to Serilog. And we're adding some additional configuration for the File sink in the Serilog.WriteTo configuration section. We can configure the output path for the log files, the naming format, which formatter to use for the logs and so on.

"Serilog": {
  "Using": [ "Serilog.Sinks.Console", "Serilog.Sinks.File" ],
  "MinimumLevel": {
    "Default": "Information",
    "Override": {
      "Microsoft": "Warning",
      "System": "Warning"
    }
  },
  "WriteTo": [
    { "Name": "Console" },
    {
      "Name": "File",
      "Args": {
        "path": "/logs/log-.txt",
        "rollingInterval": "Day",
        "rollOnFileSizeLimit": true,
        "formatter": "Serilog.Formatting.Compact.CompactJsonFormatter, Serilog.Formatting.Compact"
      }
    }
  ],
  "Enrich": [ "FromLogContext", "WithMachineName", "WithThreadId" ]
}

You can get a more detailed overview of what's supported with the Serilog.Configuration library in the documentation.

Using Serilog In ASP.NET Core

We managed to successfully install and configure Serilog. But how do we actually use it?

Serilog integrates with the ILogger interaface coming from the Microsoft.Extensions.Logging namespace. If you're already using ILogger for logging, everything will continue working correctly.

Here's a simple example of logging inside of a Minimal API endpoint:

app.MapGet("/serilog-is-cool", (ILogger logger) =>
{
    logger.LogInformation("This is a log inside of the Minimal API endpoint.");

    return Results.Ok(new { Message = "success" });
});

You just inject an ILogger or ILogger<T> instance and Serilog will provide its own implementation at runtime.

Structured Logging Syntax

The idea behind structured logging is that you can introduce additional contextual information inside of your logs. Serilog does this using a message template syntax, where you can specify named parameters and then pass in their values separately.

Here's an example of what this message template would look like. You specify parameters inside of curly bracers and provide a name, for example {NamedParameter}. The value provided for the parameter will be serialized as a property inside of the corresponding structured log.

var book = new { Author = "Domain-Driven Design", Title = "Eric Evans" };
var orderNumber = 1;

log.LogInformation(
    "Processing book {@Book}, order number = {@OrderNumber}",
    book,
    orderNumber);

There are a few things to unpack here:

  • {@Book} parameter which accepts an object
  • {OrderNumber} parameter which accepts a scalar value

The @ operator in front of Book tells Serilog to serialize the object passed in, instead of converting it using ToString().

Benefits Of Structured Logging

Lastly, I want to highlight what are some of the benefits of structured logging and why you should be using it.

As I said at the beginning, the main idea with structured logging is that all log message follow the same structure. This structure can be a JSON document for example, or a row in a relational table. Since structured logs are in a machine-readable format, it's much easier to search through them for specific information.

When an error occurs, structured logs can provide more context and details about the error, making it easier to identify the root cause and fix the problem.

It's very easy to start doing structured logging with Serilog, and I hope you'll give it a try.
