Sooner or later, every .NET developer needs to generate PDF reports. And generating polished PDF reports in .NET doesn't have to be painful. Let me explain how.

My go-to method?

HTML to PDF conversion. It's:

Simple to implement
Very flexible
Ideal for stylized reports

But many popular libraries require a commercial license. This post walks you through a completely free approach using:

Handlebars.NET for templating
PuppeteerSharp for headless rendering

This gives you full control over layout, styling, and content. It's perfect for invoices, dashboards, and exports.

We'll start from scratch and build up to a complex, dynamic invoice report with full styling, images, and even headers and footers.

Why HTML + Headless Browser?

Pros:

Rich styling with CSS
Easy to preview/debug in browser
Supports charts/images via JS/CSS
Full control over layout (media queries, page breaks, etc.)

Cons:

Requires bundling a browser (e.g. Chromium)
Slower than native PDF libraries
Slightly more setup complexity

Setting Up the Project

We'll start by installing the NuGet packages we need for Handlebars and PuppeteerSharp:

Install-Package Handlebars.Net
Install-Package PuppeteerSharp

Next, we'll create our first template. It's a simple HTML document with some Handlebars placeholders. You'll notice them with the {{variable}} syntax. These placeholders will be replaced with actual data when rendering the template.

<!-- Templates/InvoiceTemplate.html -->
<!-- The file extension doesn't really matter. -->
<html lang="en">
  <head>
    <style>
      body {
        font-family: Arial;
      }
    </style>
  </head>
  <body>
    <h1>Invoice #{{Number}}</h1>

    <p>Date: {{formatDate IssuedDate}}</p>

    <h2>From:</h2>
    <p>{{SellerAddress.CompanyName}}</p>
    <p>{{SellerAddress.Email}}</p>

    <h2>To:</h2>
    <p>{{CustomerAddress.CompanyName}}</p>
    <p>{{CustomerAddress.Email}}</p>

    <h2>Items:</h2>
    <table>
      <tr>
        <th>Name</th>
        <th>Price</th>
      </tr>
      {{#each LineItems}}
      <tr>
        <td>{{Name}}</td>
        <td>{{formatCurrency Price}}</td>
      </tr>
      {{/each}}
    </table>

    <p><strong>Total: {{formatCurrency Total}}</strong></p>
  </body>
</html>

The function calls, like {{formatDate IssuedDate}}, are custom helpers we can define in Handlebars. You register them like this:

Handlebars.RegisterHelper("formatDate", (context, arguments) =>
{
    if (arguments[0] is DateOnly date)
    {
        return date.ToString("dd/MM/yyyy");
    }
    return arguments[0]?.ToString() ?? "";
});

This allows us to format dates, currencies, or any other data type as needed. You register these helpers before compiling the template, once per application start is enough.

Rendering the Template and PDF

How do we render this template and convert it to PDF? We'll use Handlebars.NET to compile the template with data, then PuppeteerSharp to render it to PDF.

First, we read the template file and compile it with Handlebars:

var template = File.ReadAllText("Templates/InvoiceTemplate.html");
var data = new {
    customer = "Milan Jovanović",
    items = new[] {
        new { description = "Software License", price = 99 },
        new { description = "Support Plan", price = 49 }
    }
};

var compiledTemplate = Handlebars.Compile(template);

string html = compiledTemplate(data);

This gives us the final HTML with all placeholders replaced by actual data.

Note: You don't necessarily need to use Handlebars. You can use any templating engine that suits your needs, like Razor or Scriban.

Next, we need to convert this HTML to PDF using PuppeteerSharp. We'll launch a headless browser, set the content to our HTML, and then generate the PDF. Here's how we do it:

// Ensure PuppeteerSharp has the browser binaries
var browserFetcher = new BrowserFetcher();
await browserFetcher.DownloadAsync(BrowserFetcher.DefaultChromiumRevision);

// Launch the browser and create a new page
using var browser = await Puppeteer.LaunchAsync(new LaunchOptions { Headless = true });
using var page = await browser.NewPageAsync();

// Set the content of the page to our compiled HTML
await page.SetContentAsync(html);

// Optional: wait for fonts to load if using custom fonts
await page.EvaluateExpressionHandleAsync("document.fonts.ready");

byte[] pdf = await page.PdfDataAsync(new PdfOptions {
    Format = PaperFormat.A4,
    PrintBackground = true,
    MarginOptions = new MarginOptions
    {
        Top = "50px",
        Right = "20px",
        Bottom = "50px",
        Left = "20px"
    }
});

This gives us a byte array containing the PDF data. You can then save it to a file or return it from an API endpoint.

Here's a simple example of returning it from a Minimal API endpoint:

return Results.File(pdf, "application/pdf", "invoice.pdf");

Here's what the document looks like when rendered:

This is a simple PDF template example with dynamic templated content.

Simple PDF Template example rendered as PDF — This is a simple PDF template example with dynamic templated content.

Enhancements: Images, Header/Footer, Styling

What are some improvements we can make to this basic setup?

For example, you can add images to your template using the <img> tag. A simple approach is to use a base64-encoded image directly in the HTML. Note that we're passing the image data using the LogoBase64 variable.

<img
  alt="Logo"
  style="height:50px; max-width:200px; object-fit:contain;"
/>

We can also render dynamic headers and footers using PuppeteerSharp's built-in support. You can define these in the PdfOptions object when generating the PDF. Here's an example:

var pdfOptions = new PdfOptions
{
    HeaderTemplate =
        @"""
        <div style='font-size: 14px; text-align: center; padding: 10px;'>
            <span style='margin-right: 20px;'><span class='title'></span></span>
            <span><span class='date'></span></span>
        </div>
        """,
    FooterTemplate =
        @"""
        <div style='font-size: 14px; text-align: center; padding: 10px;'>
            <span style='margin-right: 20px;'>Generated on <span class='date'></span></span>
            <span>Page <span class='pageNumber'></span> of <span class='totalPages'></span></span>
        </div>
        """,
    DisplayHeaderFooter = true
};

PuppeteerSharp uses CSS classes like title, date, pageNumber, and totalPages to inject dynamic values. This could be different for some other libraries, so check the documentation.

Lastly, I want to mention that you can use CSS for advanced styling. This can be inline in the HTML or in a separate CSS file. You can also reference external stylesheets if needed, using the <link> tag.

Here's a complete example of a more complex template with images, headers, and footers:

<html lang="en">
  <head>
    <meta charset="UTF-8" />
    <meta name="viewport" content="width=device-width, initial-scale=1.0" />
    <title>Invoice #{{Number}}</title>
    <style>
      /* Omitted for brevity */
    </style>
  </head>
  <body>
    <div class="invoice-container">
      <!-- Header with Logo -->
      <div
        style="display: flex; justify-content: space-between; align-items: flex-start;"
      >
        <div>
          <h1 class="invoice-title">Invoice #{{Number}}</h1>
          <div class="invoice-dates">
            <p><strong>Issued:</strong> {{formatDate IssuedDate}}</p>
            <p><strong>Due:</strong> {{formatDate DueDate}}</p>
          </div>
        </div>
        <div>
          {{#if LogoBase64}}
          <img
            alt="Logo"
            style="height:50px; max-width:200px; object-fit:contain;"
          />
          {{/if}}
        </div>
      </div>
      <hr
        style="margin: 20px 0; border: none; border-top: 1px solid #e9ecef;"
      />

      <!-- Addresses - Side by Side -->
      <div class="addresses">
        <!-- Seller Address -->
        <div class="address-box">
          <h3 class="address-title">From:</h3>
          <div class="address-content">
            <p class="company-name">{{SellerAddress.CompanyName}}</p>
            <p>{{SellerAddress.Street}}</p>
            <p>{{SellerAddress.City}}, {{SellerAddress.State}}</p>
            <p class="email">{{SellerAddress.Email}}</p>
          </div>
        </div>

        <!-- Customer Address -->
        <div class="address-box">
          <h3 class="address-title">Bill To:</h3>
          <div class="address-content">
            <p class="company-name">{{CustomerAddress.CompanyName}}</p>
            <p>{{CustomerAddress.Street}}</p>
            <p>{{CustomerAddress.City}}, {{CustomerAddress.State}}</p>
            <p class="email">{{CustomerAddress.Email}}</p>
          </div>
        </div>
      </div>

      <!-- Items Table -->
      <div class="items-section">
        <h2 class="items-title">Items</h2>
        <table class="items-table">
          <thead>
            <tr>
              <th>#</th>
              <th>Description</th>
              <th>Price</th>
              <th>Qty</th>
              <th>Total</th>
            </tr>
          </thead>
          <tbody>
            {{#each LineItems}}
            <tr>
              <td>{{@index}}</td>
              <td>{{Name}}</td>
              <td>{{formatCurrency Price}}</td>
              <td>{{formatNumber Quantity}}</td>
              <td>{{formatCurrency (multiply Price Quantity)}}</td>
            </tr>
            {{/each}}
          </tbody>
        </table>
      </div>

      <!-- Totals -->
      <div class="totals">
        <div class="totals-container">
          <div class="totals-row subtotal">
            <span>Subtotal:</span>
            <span>{{formatCurrency Subtotal}}</span>
          </div>
          <div class="totals-row">
            <span>Tax:</span>
            <span>{{formatCurrency 0}}</span>
          </div>
          <div class="totals-row total">
            <span>Total:</span>
            <span>{{formatCurrency Total}}</span>
          </div>
        </div>
      </div>
    </div>
  </body>
</html>

And the rendered PDF looks like this:

This is a complex PDF template example with CSS stylization, tables, images, headers, and footers.

Complex PDF Template example rendered as PDF with images, headers, and footers — This is a complex PDF template example with CSS stylization, tables, images, headers, and footers.

Downloading Binaries at Application Start

Here's a small tip: PuppeteerSharp requires the Chromium browser binaries to be downloaded at runtime. You can do this by calling BrowserFetcher.DownloadAsync() before launching the browser. This ensures the required browser version is available when you run your application.

A simple way to do this is to add it to your application startup code or a background service:

public class BrowserSetupService : BackgroundService
{
    protected override async Task ExecuteAsync(CancellationToken stoppingToken)
    {
        var browserFetcher = new BrowserFetcher();
        await browserFetcher.DownloadAsync();
    }
}

Then register this service in your Program.cs:

builder.Services.AddHostedService<BrowserSetupService>();

Performance Considerations

Let's talk about performance. How fast is this approach and can you use it at scale?

The first thing to consider is the use a headless browser like Chromium. This can be slower than native PDF libraries, especially for large documents or high concurrency. It also adds overhead at runtime since the browser binaries need to be downloaded and launched.

You should definitely consider moving this out of your main application. You can use a background service or a separate microservice to handle PDF generation. Event a cloud function can be a good fit if you need to scale.

But as with anything performance-related, it depends on your specific use case. So measure and profile your application to see if this approach meets your needs.

Here are some benchmarks I ran on a sample invoice template. It's nothing scientific, but it gives you an idea of the performance. I didn't test this with concurrent requests, but rather just the time it takes to generate a single PDF.

Cold Start: ~12s spent downloading + launching Chromium

Warm Run: ~580ms

Template + HTML generation: ~13ms
Browser reuse + rendering: ~550ms

Summary

HTML + PuppeteerSharp is one of the most pragmatic approaches for PDF reporting in .NET.

It lets you:

Design pixel-perfect layouts using familiar web technologies
Inject dynamic data cleanly with Handlebars.NET
Output high-quality PDFs with full styling, tables, and images

And all of this without relying on commercial libraries.

I've also written about PDF generation in the past, with libraries like QuestPdf or IronPdf. You can take a look at those if you want to compare approaches.

The cold start can be expensive, but once warmed up, rendering is fast and reliable. You get total layout control, CSS styling, and even dynamic headers and footers with page numbers and timestamps.

If you're building internal dashboards, invoice generators, or export endpoints, this approach delivers excellent value.

If you need pixel-perfect PDF reports in .NET and want full design control, combining Handlebars.NET with PuppeteerSharp is a powerful approach.

You'll trade some performance and setup cost for flexibility, but for most internal tools, dashboards, or customer-facing reports, it's worth it.
