**Software architecture** diagrams are a great way to communicate how you are planning to build a software system or how an existing software system works.

However, the majority of software architecture **diagrams** I've seen are a total mess.

If only there was a standard way to visualize your software architecture...

Enter the **C4 model**, which stands for **context**, **containers**, **components**, and **code**.

The **C4 model** is a lightweight approach to describing your **software architecture**.

And it's essentially just two things, a predefined set of common **abstractions** and four diagram types:

- **Context diagram** - high-level view of the system
- **Container diagram** - shows the objects running inside a system
- **Component diagram** - shows the building blocks that make each container
- **Code diagram** - rarely used, typically UML or ER diagram

Let's see how we can use the **C4 model** to visualize our **software architecture**.

## First You Need Abstractions

Before we dive into the **C4 diagrams**, we first need to understand the ubiquitous language of the **C4 model**.

> A software system is made up of one or more containers (applications and data stores),
> each of which contains one or more components, which in turn are implemented by one or more code elements (classes, interfaces, objects, functions, etc).
> And people may use the software systems that we build.

The **C4 model** defines a set of **abstractions** that you can use to describe your software systems:

- Person - the end user using your system
- Software system - highest level of abstraction that delivers value to end users
- Container - applications and data stores that make up a system
- Component - building blocks/modules that make up the container

With these high-level concepts in place, let's take a look at how to use them in our **C4 diagrams**.

## System Context Diagram

The **System Context diagram** is a high-level view of your software system.

It shows your software system as the central part, and any external systems and users that your system interacts with.

It should be **technology agnostic**, and the focus on the people and software systems instead of low-level details.

<Image
  src="blogs/mnw_037/system_context_diagram.jpg"
  width={2116}
  height={1172}
/>

The intended audience for the **System Context Diagram** is _everybody_.

If you can show it to non-technical people and they are able to understand it, then you know you're on the right track.

## Container Diagram

When you zoom into one software system, you get to the **Container diagram**.

Your software system is comprised of multiple running parts - **containers**.

A **container** can be a:

- Web application
- Single-page application
- Database
- File system
- Object store
- Message broker

You can look at a **container** as a **deployment unit** that executes code or stores data.

The **Container diagram** shows the high-level view of the software architecture and the **major technology choices**.

<Image src="blogs/mnw_037/container_diagram.jpg" width={1972} height={1732} />

The **Container diagram** is intended for technical people inside and outside of the software development team:

- Software architects
- Developers
- Operations/support staff

## Component Diagram

Next you can zoom into an individual **container** to decompose it into its building blocks.

The **Component diagram** show the individual **components** that make up a **container**:

- What each of the components are
- The technology and implementation details

<Image src="blogs/mnw_037/component_diagram.jpg" width={2100} height={1524} />

The **Component diagram** is intended for software architects and developers.

## Code Diagram

Finally, you can zoom into each **component** to show how it is implemented with **code**, typically using a UML class diagram or an ER diagram.

This level is rarely used as it goes into too much technical detail for most use cases.

However, there are supplementary diagrams that can be useful to fill in missing information by showcasing:

- Sequence of events
- Deployment information
- How systems interact at a higher level

It's only recommended for the most **important or complex components**.

Of course, the target audience are software architects and developers.

## Takeaway

The **C4 model** is a tool for visual and verbal communication, enabling your team to talk in the same language and have a common understanding of the design.

It's valuable for many reasons, to name a few:

- Product and business people benefit from understanding user behavior at the Context level
- Context and Container diagrams provide a simple view of how software systems work
- New developers can quickly understand system flows

Now that you understand what the **C4 model** is, there's one question left to answer.

Should you use the **C4 model** to express your **software architecture**?

I can't give you a definitive answer.

I used it with a lot of success.

But I think you should at least give it a try.

You can learn more about the **C4 model** [here.](https://c4model.com/)

Thank you for reading, and have an awesome Saturday.

---



<Sponsorships>

Today's issue is sponsored by [**Hasura**](https://hasura.io/graphql/database/sql-server/?utm_source=newsletter&utm_medium=email&utm_campaign=milan-dotnet-weekly),
an open-source engine that gives
[**instant GraphQL and REST APIs on new or existing SQL Server**](https://hasura.io/graphql/database/sql-server/?utm_source=newsletter&utm_medium=email&utm_campaign=milan-dotnet-weekly),
enabling teams to ship apps faster.

And by [**Rebus Pro.**](https://pro.rebus.fm)
Rebus is a free .NET "service bus", and [**Rebus Pro is the perfect one-up for serious Rebus users.**](https://pro.rebus.fm)
Use Fleet Manager to get Slack alerts when something fails and retry dead-lettered messages with a click of the mouse.

</Sponsorships>

**Software architecture** is a blueprint for how you should structure your system.
You can follow this blueprint strictly, or you can give yourself varying levels of freedom.

But when deadlines are tight, and you start cutting corners, that beautiful software architecture you built crumbles like a house of cards.

How can you **enforce** your **software architecture**?

By writing **architecture tests**.

**Architecture tests** are automated tests that verify the structure and design of your code.

You can use them to enforce your software architecture and the direction of dependencies of your projects.

In this week's issue I'll explain how to:

- Write architecture tests
- Enforce architecture
- Enforce design rules

Let's dive in!

## Writing Architecture Tests

You write **architecture tests** the same as any unit test in your application.
There's an excellent library for writing architecture tests that already implements the boilerplate code we need to start writing tests.

We're going to use the `NetArchTest.Rules` library for writing architecture tests.

First, you have to install the NuGet package:

```powershell
Install-Package NetArchTest.Rules
```

And now you can use it to write rules in your test project.

The starting point for writing architecture tests is the static `Types` class, which you can use to load a set of types.

Once you have loaded your types you can further filter them to find a more specific set of types.

Some of the available filtering methods:

- `ResideInNamespace`
- `AreClasses`
- `AreInterfaces`
- `HaveNameStartingWith`
- `HaveNameEndingWith`

Finally, when you are satisfied with your selection, you can write the rule you want to enforce by calling `Should` or `ShouldNot`
and applying the condition you want to check.

Here's an example checking that all classes in the domain assembly are sealed:

```csharp
var result = Types
  .InAssembly(DomainAssembly)
  .That()
  .AreClasses()
  .Should()
  .BeSealed()
  .GetResult();

Assert.True(result.IsSuccessful);
```

## Enforcing Architecture Rules

**Architecture tests** are particularly useful to **enforce software architecture rules** in a layered architecture or **Modular Monolith**.

Let's take the example of the Clean architecture:

- Domain should not have any dependencies
- Application should not depend on Infrastructure
- Infrastructure should depend on Application and Domain

Here's how you can write tests for enforcing architecture rules.

**Domain should not have any dependencies**

```csharp
var result = Types
  .InAssembly(DomainAssembly)
  .ShouldNot()
  .HaveDependencyOnAny("Application", "Infrastructure")
  .GetResult();

Assert.True(result.IsSuccessful);
```

**Application should not depend on Infrastructure**

```csharp
var result = Types
  .InAssembly(AplicationAssembly)
  .Should()
  .NotHaveDependencyOn("Infrastructure")
  .GetResult();

Assert.True(result.IsSuccessful);
```

**Infrastructure should depend on Application and Domain**

How the `NetArchTest.Rules` library works is by scanning the imported namespaces of your types.

Because of this, writing negative conditions like in the previous two examples is straightforward.

But writing positive conditions has to be scoped to a more specific set of types.

For example, we can validate this dependency by checking that all repositories must have a dependency on the `Domain` namespace.

```csharp
var result = Types
  .InAssembly(InfrastructureAssembly)
  .HaveNameEndingWith("Repository")
  .Should()
  .HaveDependencyOn("Domain")
  .GetResult();

Assert.True(result.IsSuccessful);
```

## Enforcing Design Rules

Another valuable **use case** for **architecture tests** is **enforcing design rules** in your application.

Design rules are more specific than project references, and focus on the implementation details of your classes.

Here are some **design rules** that you can enforce:

- Services must be internal
- Entities and Value objects must be sealed
- Controllers can't depend on repositories directly
- Command (or query) handlers must follow a naming convention

The possibilities are endless, and it's up to you how many design rules you want to enforce.

Here's how you can write tests for enforcing design rules.

**Command handlers must end with `CommandHandler`**

```csharp
var result = Types
    .InAssembly(ApplicationAssembly)
    .That()
    .ImplementInterface(typeof(ICommandHandler))
    .Should()
    .HaveNameEndingWith("CommandHandler")
    .GetResult();

Assert.True(result.IsSuccessful);
```

**Controllers can't directly reference repositories**

```csharp
var result = Types
    .InAssembly(ApiAssembly)
    .That()
    .HaveNameEndingWith("Controller")
    .ShouldNot()
    .HaveDependencyOn("Infrastructure.Repositories")
    .GetResult();

Assert.True(result.IsSuccessful);
```

## Takeaway

**Architecture tests** are an easy way to **enforce software architecture** and design rules with automated tests.

One of the best investments you can make as a software engineer is writing automated tests.
You write the tests once, and use them to verify your system forever.
Granted, you also have to maintain the tests over time as your system grows.

Manually enforcing software architecture with pair programming and constant PR reviews is:

- Error prone
- Time consuming
- Not cost effective

**Architecture tests** really shine here, since you can write them quickly and reduce the cost of enforcing your software architecture rules to zero.

Thanks for reading.

Hope that was helpful!

---



<Sponsorships>

Today's issue is sponsored by [**Rebus Pro.**](https://pro.rebus.fm)
Rebus is a free .NET "service bus", and [**Rebus Pro is the perfect one-up for serious Rebus users.**](https://pro.rebus.fm)
Use Fleet Manager to get Slack alerts when something fails and retry dead-lettered messages with a click of the mouse.

And by [**Hasura**](https://hasura.io/graphql/database/sql-server/?utm_source=newsletter&utm_medium=email&utm_campaign=milan-dotnet-weekly),
an open-source engine that gives
[**instant GraphQL and REST APIs on new or existing SQL Server**](https://hasura.io/graphql/database/sql-server/?utm_source=newsletter&utm_medium=email&utm_campaign=milan-dotnet-weekly),
enabling teams to ship apps faster.

</Sponsorships>

We all want to build **robust** and **reliable** applications that can scale indefinitely and handle any number of requests.

But with **distributed systems** and **microservices architectures** growing in complexity, it's becoming increasingly harder to **monitor** the **health** of our applications.

It's vital that you have a system in place to receive quick feedback of your application **health.**

That's where **health checks** come in.

**Health checks** provide a way to monitor and verify the health of various components of an application including:

- Databases
- APIs
- Caches
- External services

Here's what I'll show you in this week's newsletter:

- [What are health checks](#what-are-health-checks)
- [Adding a custom health check](#adding-custom-health-checks)
- [Using existing health check libraries](#using-existing-health-check-libraries)
- [Customizing the health checks response format](#formatting-health-checks-response)

Let's see how to implement **health checks** in **ASP.NET Core**.

## What Are Health Checks?

**Health checks** are a proactive mechanism for monitoring and verifying the **health** and **availability** of an application in **ASP.NET Core.**

ASP.NET Core has **built-in support** for implementing **health checks.**

Here's the basic configuration, which registers the health check services and adds the `HealthCheckMiddleware` to respond at the specified URL.

```csharp {3,7}
var builder = WebApplication.CreateBuilder(args);

builder.Services.AddHealthChecks();

var app = builder.Build();

app.MapHealthChecks("/health");

app.Run();
```

The health check returns a `HealthStatus` value indicating the health of the service.

There are three distinct `HealthStatus` values:

- `HealthStatus.Healthy`
- `HealthStatus.Degraded`
- `HealthStatus.Unhealthy`

You can use the `HealthStatus` to indicate the different states of your application.

For example, if the application is functioning slower than expected you can return `HealthStatus.Degraded`.

## Adding Custom Health Checks

You can create **custom health checks** by implementing the `IHealthCheck` interface.

For example, you can implement a check to see if your **SQL** database is available.

It's important to use a query that can complete quickly in the database, like `SELECT 1`.

Here's a **custom health check** implementation example in the `SqlHealthCheck` class:

```csharp
public class SqlHealthCheck : IHealthCheck
{
    private readonly string _connectionString;

    public SqlHealthCheck(IConfiguration configuration)
    {
        _connectionString = configuration.GetConnectionString("Database");
    }

    public async Task<HealthCheckResult> CheckHealthAsync(
        HealthCheckContext context,
        CancellationToken cancellationToken = default)
    {
        try
        {
            using var sqlConnection = new SqlConnection(_connectionString);

            await sqlConnection.OpenAsync(cancellationToken);

            using var command = sqlConnection.CreateCommand();
            command.CommandText = "SELECT 1";

            await command.ExecuteScalarAsync(cancellationToken);

            return HealthCheckResult.Healthy();
        }
        catch(Exception ex)
        {
            return HealthCheckResult.Unhealthy(
                context.Registration.FailureStatus,
                exception: ex);
        }
    }
}
```

After you implement the **custom health check**, you need to register it.

The previous call to `AddHealthChecks` now becomes:

```csharp {2}
builder.Services.AddHealthChecks()
    .AddCheck<SqlHealthCheck>("custom-sql", HealthStatus.Unhealthy);
```

We're giving it a custom name and setting which status to use as the failure result in `HealthCheckContext.Registration.FailureStatus`.

But stop and think for a moment.

Do you want to implement a **custom health check** on your own for **every external service** that you have?

Of course not! There's a better solution.

## Using Existing Health Check Libraries

Before you start implementing a custom **health check** for everything, you should first see if there's already an **existing library.**

In the [`AspNetCore.Diagnostics.HealthChecks`](https://github.com/Xabaril/AspNetCore.Diagnostics.HealthChecks) repository you can find
a wide collection **health check** packages for frequently used services and libraries.

Here are just a few examples:

- SQL Server - `AspNetCore.HealthChecks.SqlServer`
- Postgres - `AspNetCore.HealthChecks.Npgsql`
- Redis - `AspNetCore.HealthChecks.Redis`
- RabbitMQ - `AspNetCore.HealthChecks.RabbitMQ`
- AWS S3 - `AspNetCore.HealthChecks.Aws.S3`
- SignalR - `AspNetCore.HealthChecks.SignalR`

Here's how to add health checks for **PostgreSQL** and **RabbitMQ**:

```csharp {3,4}
builder.Services.AddHealthChecks()
    .AddCheck<SqlHealthCheck>("custom-sql", HealthStatus.Unhealthy);
    .AddNpgSql(pgConnectionString)
    .AddRabbitMQ(rabbitConnectionString)
```

## Formatting Health Checks Response

By default, the endpoint returning you **health check** status will return a string value representing a `HealthStatus`.

This isn't practical if you have **multiple health checks** configured, as you'd want to view the health status individually per service.

To make matters worse, if one of the services is failing the entire response will return `Unhealthy` and you don't know what's causing the issue.

You can solve this by providing a `ResponsWriter`, and there's an existing one in the `AspNetCore.HealthChecks.UI.Client` library.

Let's install the **NuGet** package:

```powershell
Install-Package AspNetCore.HealthChecks.UI.Client
```

And you need to slightly update the call to `MapHealthChecks` to use the `ResponseWriter` coming from this library:

```csharp {3-6}
app.MapHealthChecks(
    "/health",
    new HealthCheckOptions
    {
        ResponseWriter = UIResponseWriter.WriteHealthCheckUIResponse
    });
```

After making these changes, here's what the response from the health check endpoint looks like:

```json
{
  "status": "Unhealthy",
  "totalDuration": "00:00:00.3285211",
  "entries": {
    "npgsql": {
      "data": {},
      "duration": "00:00:00.1183517",
      "status": "Healthy",
      "tags": []
    },
    "rabbitmq": {
      "data": {},
      "duration": "00:00:00.1189561",
      "status": "Healthy",
      "tags": []
    },
    "custom-sql": {
      "data": {},
      "description": "Unable to connect to the database.",
      "duration": "00:00:00.2431813",
      "exception": "Unable to connect to the database.",
      "status": "Unhealthy",
      "tags": []
    }
  }
}
```

## Takeaway

Application monitoring is important to track availability, resource usage, and changes to performance in your application.

I've used **health checks** before to implement **failover scenarios** in a **cloud deployment**.
When one application instance stops responding with a healthy result, a new one is created to continue serving requests.

It's easy to monitor the health of your ASP.NET Core applications by **exposing health checks** for your services.

You can decide to implement **custom health checks**, but first consider if there are **existing solutions**.

Thank you for reading, and have an awesome Saturday.

---



<Sponsorships>

Today's issue is sponsored by [**Hasura**](https://hasura.io/graphql/database/sql-server/?utm_source=newsletter&utm_medium=email&utm_campaign=milan-dotnet-weekly),
an open-source engine that gives
[**instant GraphQL and REST APIs on new or existing SQL Server**](https://hasura.io/graphql/database/sql-server/?utm_source=newsletter&utm_medium=email&utm_campaign=milan-dotnet-weekly),
enabling teams to ship apps faster.

And by [**Rebus Pro.**](https://pro.rebus.fm)
Rebus is a free .NET "service bus", and [**Rebus Pro is the perfect one-up for serious Rebus users.**](https://pro.rebus.fm)
Use Fleet Manager to get Slack alerts when something fails and retry dead-lettered messages with a click of the mouse.

</Sponsorships>

What happens when a **message is retried** in an event-driven system?

It happens more often than you think.

The **worst case scenario** is that the **message is processed twice**, and the **side effects** can also be applied more than once.

Do you want your bank account to be double charged?

I'll assume the answer is no, of course.

You can use the **Idempotent Consumer** pattern to solve this problem.

In this week's issue I will show you:

- How the Idempotent Consumer pattern works
- How to implement an Idempotent Consumer
- The tradeoffs you need to consider

Let's see why the **Idempotent Consumer** pattern is valuable.

## How The Idempotent Consumer Pattern Works

What's the idea behind the **Idempotent Consumer pattern**?

> An idempotent operation is one that has no additional effect if it is called more than once with the same input parameters.

We want to avoid handling the same message more than once.

This would require **Exactly-once** message delivery guarantees from our messaging system.
And this is a really hard problem to solve in distributed systems.

A looser delivery guarantee is **At-least-once**, where we are aware that retries can happen and we can receive the same message more than once.

The **Idempotent Consumer** pattern works well with **At-least-once** message delivery, and solves the **problem of duplicate messages.**

Here's what the algorithm looks like from the moment we receive a message:

1. Was the message already processed?
2. If yes, it's a duplicate and there's nothing to do
3. If not, we need to handle the message
4. We also need to store the message identifier

<Image
  src="blogs/mnw_034/idempotent_consumer_algorithm.png"
  width={400}
  height={634}
/>

We need a **unique identifier** for every **message** we receive, and a table in the database to store processed messages.

However, it's interesting how we choose the implement the message handling and storing of the processed message identifier.

You can implement the idempotent consumer as a decorator around a regular message handler.

I'll show you two implementations:

- Lazy idempotent consumer
- Eager idempotent consumer

## Lazy Idempotent Consumer

The **lazy idempotent consumer** matches the flow shown in the algorithm above.

Lazy refers to how we store the message identifer to mark it as processed.

In the happy path, we handle the message and store the message identifier.

If the message handler throws an exception, we never store the message identifier and the consumer can be executed again.

Here's what the implementation looks like:

```csharp
public class IdempotentConsumer<T> : IHandleMessages<T>
    where T : IMessage
{
    private readonly IMessageRepository _messageRepository;
    private readonly IHandleMessages<T> _decorated;

    public IdempotentConsumer(
        IMessageRepository messageRepository,
        IHandleMessages<T> decorated)
    {
        _messageRepository = messageRepository;
        _decorated = decorated;
    }

    public async Task Handle(T message)
    {
        if (_messageRepository.IsProcessed(message.Id))
        {
            return;
        }

        await _decorated.Handle(message);

        _messageRepository.Store(message.Id);
    }
}
```

## Eager Idempotent Consumer

The **eager idempotent consumer** is slightly different from the lazy implementation, but the end result is the same.

In this version, we eagerly store the message identifier in the database and then continue to handle the message.

If the handler throws an exception, we need to perform cleanup in the database and remove the eagerly stored message identifier.

Otherwise, we risk leaving the system in an inconsistent state since the message was never handled correctly.

Here's what the implementation looks like:

```csharp
public class IdempotentConsumer<T> : IHandleMessages<T>
    where T : IMessage
{
    private readonly IMessageRepository _messageRepository;
    private readonly IHandleMessages<T> _decorated;

    public IdempotentConsumer(
        IMessageRepository messageRepository,
        IHandleMessages<T> decorated)
    {
        _messageRepository = messageRepository;
        _decorated = decorated;
    }

    public async Task Handle(T message)
    {
        try
        {
            if (_messageRepository.IsProcessed(message.Id))
            {
                return;
            }

            _messageRepository.Store(message.Id);

            await _decorated.Handle(message);
        }
        catch (Exception e)
        {
            _messageRepository.Remove(message.Id);

            throw;
        }
    }
}
```

## In Summary

Idempotency is an interesting problem to solve in a software system.

Some operations are **naturally idempotent**, and we don't need the overhead of the **Idempotent Consumer** pattern.

However, for those operations that aren't naturally idempotent, the **Idempotent Consumer** is a great solution.

The high-level algorithm is simple, and you can take two approaches in the implementation:

- Lazy storing of message identifiers
- Eager storing of message identifiers

I prefer to use the **lazy approach**, and only **store the message identifier** in the database when the **handler completes successfully.**

It's easier to reason about and there is one less call to the database.

Thanks for reading.

Hope that was helpful.

---



<Sponsorships>

This week's issue is sponsored by the [**Why You Should Join Newsletter.**](https://whyyoushouldjoin.substack.com/)
[**Why You Should Join**](<(https://whyyoushouldjoin.substack.com/)>) is a free, monthly newsletter doing deep dives on the most promising startups to join.
They receive inside info from Sequoia, Index, and [**other top VCs**](https://whyyoushouldjoin.substack.com/about) about which companies are doing best and recommend just one each month.
Prior suggestions [**Warp**](https://whyyoushouldjoin.substack.com/p/warp) and [**Pinecone**](https://whyyoushouldjoin.substack.com/p/pinecone)
have since raised significant follow-on funding - [**subscribe for free**](https://whyyoushouldjoin.substack.com/) so you don't miss the next Uber or Airbnb.

And by [**Hasura**](https://hasura.io/graphql/database/sql-server/?utm_source=newsletter&utm_medium=email&utm_campaign=milan-dotnet-weekly),
an open-source engine that gives
[**instant GraphQL and REST APIs on new or existing SQL Server**](https://hasura.io/graphql/database/sql-server/?utm_source=newsletter&utm_medium=email&utm_campaign=milan-dotnet-weekly),
enabling teams to ship apps faster.

</Sponsorships>

**EF Core** is getting many new and exciting features in the upcoming version.

**EF7** introduced support for returning **scalar types** using **SQL** queries.

And now we're getting support for **querying unmapped types** with **raw SQL queries** in **EF8.**

This is exactly what **Dapper** offers out of the box, and it's good to see **EF Core** catching up.

In this week's newsletter, I'm going to cover how to use **EF Core** for:

- [Raw SQL queries](#ef-core-and-sql-queries)
- [Composing SQL queries with LINQ](#composing-sql-queries-with-linq)
- [Executing data modifications with SQL](#sql-queries-for-data-modifications)

Let's dive in!

## EF Core And SQL Queries

**EF7** added support for **raw SQL queries** returning scalar types.
**EF8** is taking this a step further with raw SQL queries that can return any mappable type, without having to include it in the **EF model**.

You can query unmapped types with the `SqlQuery` and `SqlQueryRaw` methods.

The `SqlQuery` method uses string interpolation to parameterize the query, protecting against SQL injection attacks.

Here's an example query returning an `OrderSummary` list:

```csharp
var startDate = new DateOnly(2023, 1, 1);

var ordersIn2023 = await dbContext
    .Database
    .SqlQuery<OrderSummary>(
        $"SELECT * FROM OrderSummaries AS o WHERE o.CreatedOn >= {startDate}")
    .ToListAsync();
```

This will be the **SQL** sent to the database:

```sql
SELECT * FROM OrderSummaries AS o WHERE o.CreatedOn >= @p0
```

The type used for the query result can have a parameterized constructor.
The property names don't need to match the column names in the database, but they do have to match the names of the values in the result set.

You can also execute raw SQL queries and return results with:

- Views
- Functions
- Stored procedures

## Composing SQL Queries With LINQ

An interesting thing about `SqlQuery` is that it returns `IQueryable`, which can be further composed with **LINQ.**

You can add a `Where` statement after calling `SqlQuery`:

```csharp
var startDate = new DateOnly(2023, 1, 1);

var ordersIn2023 = await dbContext
    .Database
    .SqlQuery<OrderSummary>("SELECT * FROM OrderSummaries AS o")
    .Where(o => o.CreatedOn >= startDate)
    .ToListAsync();
```

However, the generated **SQL** isn't optimal:

```sql
SELECT s.Id, s.CustomerId, s.TotalPrice, s.CreatedOn
FROM (
    SELECT * FROM OrderSummaries AS o
) AS s
WHERE s.CreatedOn >= @p0
```

Another possibility is to combine an `OrderBy` statement with `Skip` and `Take`:

```csharp
var startDate = new DateOnly(2023, 1, 1);

var ordersIn2023 = await dbContext
    .Database
    .SqlQuery<OrderSummary>(
        $"SELECT * FROM OrderSummaries AS o WHERE o.CreatedOn >= {startDate}")
    .OrderBy(o => o.Id)
    .Skip(10)
    .Take(5)
    .ToListAsync();
```

This would be the generated **SQL** for the previous query:

```sql
SELECT s.Id, s.CustomerId, s.TotalPrice, s.CreatedOn
FROM (
    SELECT * FROM OrderSummaries AS o WHERE o.CreatedOn >= @p0
) AS s
ORDER BY s.Id
OFFSET @p1 ROWS FETCH NEXT @p2 ROWS ONLY
```

In case you're wondering, the performance is similar to **LINQ** queries using `Select` projections.

I ran some benchmarks, and didn't notice any significant performance improvement.

This feature will be very useful if you're more comfortable with writing **SQL** or you want to fetch data from views, functions, and stored procedures.

## SQL Queries For Data Modifications

If you want to modify data in the database with **SQL**, you will typically write a query that doesn't return a result.

The SQL query can be an `UPDATE` or `DELETE` statement, or even a stored procedure call.

You can use the `ExecuteSql` method to execute this type of query with **EF Core**:

```csharp
var startDate = new DateOnly(2023, 1, 1);

dbContext.Database.ExecuteSql(
    $"UPDATE Orders SET Status = 5 WHERE CreatedOn >= {startDate}");
```

`ExecuteSql` also protects from SQL injection by parameterizing arguments, just like `SqlQuery`.

With **EF7** you can write the above query with **LINQ** and the `ExecuteUpdate` method.
There's also the `ExecuteDelete` method for deleting records.

## In Summary

**EF7** introduced support for raw SQL queries returning **scalar** values.

**EF8** will add support for **raw SQL queries** returning **unmapped types** with `SqlQuery` and `SqlQueryRaw`.

I like the direction that **EF** is going, introducing more flexibility for querying the database.

The performance isn't as good as **Dapper**, unfortunately.
But it's close enough that network costs will play the bigger factor.

I will probably be using only **EF** moving forward since it covers more use cases.

Thank you for reading, and have an awesome Saturday.

---



<Sponsorships>

Today's issue is sponsored by [**Rebus Pro.**](https://pro.rebus.fm)
Rebus is a free .NET "service bus", and [**Rebus Pro is the perfect one-up for serious Rebus users.**](https://pro.rebus.fm)
Use Fleet Manager to get Slack alerts when something fails and retry dead-lettered messages with a click of the mouse.

And by [**Hasura**](https://hasura.io/graphql/database/sql-server/?utm_source=newsletter&utm_medium=email&utm_campaign=milan-dotnet-weekly),
an open-source engine that gives
[**instant GraphQL and REST APIs on new or existing SQL Server**](https://hasura.io/graphql/database/sql-server/?utm_source=newsletter&utm_medium=email&utm_campaign=milan-dotnet-weekly),
enabling teams to ship apps faster.

</Sponsorships>

Rate limiting is a technique to limit the number of requests to a server or an API.

A limit is introduced within a given time period to prevent server overload and protect against abuse.

In ASP.NET Core 7, we have a built-in rate limiter middleware that's easy to integrate into your API.

We're going to cover four rate limiter algorithms:

- [Fixed window](#fixed-window-limiter)
- [Sliding window](#sliding-window-limiter)
- [Token bucket](#token-bucket-limiter)
- [Concurrency](#concurrency-limiter)

Let's see how we can work with rate limiting.

## What Is Rate Limiting?

Rate limiting is about restricting the number of requests to an API, usually within a specific time window or based on other criteria.

This is practical for a few reasons:

- Prevents overloading of servers or applications
- Improves security and guards against DDoS attacks
- Reduces costs by preventing unnecessary resource usage

In a multi-tenant application, each unique user can have a limitation on the number of API requests.

## Configuring Rate Limiting

ASP.NET Core 7 introduced built-in rate limiting middleware in the `Microsoft.AspNetCore.RateLimiting` namespace.

To add rate limiting to your application, you first need to register the rate limiting services:

```csharp
builder.Services.AddRateLimiter(options =>
{
    options.RejectionStatusCode = StatusCodes.Status429TooManyRequests;

    // We'll talk about adding specific rate limiting policies later.
});
```

I suggest updating the `RejectionStatusCode` to `429 (Too Many Requests)` because it's more correct.
The default value is `503 (Service Unavailable)`.

And you also have to apply the `RateLimitingMiddleware`:

```csharp
app.UseRateLimiter();
```

That's everything you'll need.

Let's see the rate limiting algorithms we can use.

## Fixed Window Limiter

The `AddFixedWindowLimiter` method configures a fixed window limiter.

The `Window` value determines the time window.

When a time window expires, a new one starts, and the request limit is reset.

```csharp
builder.Services.AddRateLimiter(rateLimiterOptions =>
{
    rateLimiterOptions.AddFixedWindowLimiter("fixed", options =>
    {
        options.PermitLimit = 10;
        options.Window = TimeSpan.FromSeconds(10);
        options.QueueProcessingOrder = QueueProcessingOrder.OldestFirst;
        options.QueueLimit = 5;
    });
});
```

## Sliding Window Limiter

The sliding window algorithm is similar to the fixed window, but it introduces segments in a window.

Here's how it works:

- Each time window is divided into multiple segments
- The window slides one segment each segment interval
- The segment interval is (window_time)/(segments_per_window)
- When a segment expires, the requests taken in that segment are added to the current segment

The `AddSlidingWindowLimiter` method configures a sliding window limiter.

```csharp
builder.Services.AddRateLimiter(rateLimiterOptions =>
{
    rateLimiterOptions.AddSlidingWindowLimiter("sliding", options =>
    {
        options.PermitLimit = 10;
        options.Window = TimeSpan.FromSeconds(10);
        options.SegmentsPerWindow = 2;
        options.QueueProcessingOrder = QueueProcessingOrder.OldestFirst;
        options.QueueLimit = 5;
    });
});
```

## Token Bucket Limiter

The token bucket algorithm is similar to the sliding window, but instead of adding back the requests from the expired segment,
a fixed number of tokens are added after each replenishment period.

The total number of tokens can never exceed the token limit.

The `AddTokenBucketLimiter` method configures a token bucket limiter.

```csharp
builder.Services.AddRateLimiter(rateLimiterOptions =>
{
    rateLimiterOptions.AddTokenBucketLimiter("token", options =>
    {
        options.TokenLimit = 100;
        options.QueueProcessingOrder = QueueProcessingOrder.OldestFirst;
        options.QueueLimit = 5;
        options.ReplenishmentPeriod = TimeSpan.FromSeconds(10);
        options.TokensPerPeriod = 20;
        options.AutoReplenishment = true;
    });
});
```

When `AutoReplenishment` is `true`, an internal timer will execute every `ReplenishmentPeriod` and replenish the tokens.

## Concurrency Limiter

The concurrency limiter is the most straightforward algorithm, and it just limits the number of concurrent requests.

The `AddConcurrencyLimiter` method configures a concurrency limiter.

```csharp
builder.Services.AddRateLimiter(rateLimiterOptions =>
{
    rateLimiterOptions.AddConcurrencyLimiter("concurrency", options =>
    {
        options.PermitLimit = 10;
        options.QueueProcessingOrder = QueueProcessingOrder.OldestFirst;
        options.QueueLimit = 5;
    });
});
```

There's no time component involved in this case. The only parameter is the number of concurrent requests.

## Using Rate Limiting In Your API

Now that we have configured our rate limiting policies, let's see how we can use them in our API.

There are slight differences between controllers and minimal API endpoints, so I'll cover them in separate examples.

**Controllers**

To add rate limiting on a controller we use the `EnableRateLimiting` and `DisableRateLimiting` attributes.

`EnableRateLimiting` can be applied on the controller or on the individual endpoints.

```csharp
[EnableRateLimiting("fixed")]
public class TransactionsController
{
    private readonly ISender _sender;

    public TransactionsController(ISender sender)
    {
        _sender = sender;
    }

    [EnableRateLimiting("sliding")]
    public async Task<IActionResult> GetTransactions()
    {
        return Ok(await _sender.Send(new GetTransactionsQuery()));
    }

    [DisableRateLimiting]
    public async Task<IActionResult> GetTransactionById(int id)
    {
        return Ok(await _sender.Send(new GetTransactionByIdQuery(id)));
    }
}
```

In the previous example:

- All endpoints in the `TransactionsController` will use a **fixed window** policy
- The `GetTransactions` endpoint will use a **sliding window** policy
- The `GetTransactionById` endpoint won't have any rate limiting applied

**Minimal APIs**

In a Minimal API endpoint you can configure the rate limit policy by calling `RequireRateLimiting` and specifying the policy name.

We're using the **token bucket** policy in this example.

```csharp
app.MapGet("/transactions", async (ISender sender) =>
{
    return Results.Ok(await sender.Send(new GetTransactionsQuery()));
})
.RequireRateLimiting("token");
```

## Closing Thoughts

It's great that we can quickly introduce **rate limiting** in ASP.NET Core.

You can choose from one of the existing rate limiter algorithms:

- Fixed window
- Sliding window
- Token bucket
- Concurrency

Here are some resources if you want to learn more about rate limiting:

- [Rate Limiting pattern](https://learn.microsoft.com/en-us/azure/architecture/patterns/rate-limiting-pattern)
- [Announcing Rate Limiting for .NET](https://devblogs.microsoft.com/dotnet/announcing-rate-limiting-for-dotnet/)

I'm excited to try out rate limiting in my projects.

That's all for today.

Have an awesome Saturday!

---



<Sponsorships>

This week's issue is sponsored by [**QueueExplorer.**](https://www.cogin.com/mq/)
QueueExplorer is an explorer-like [**management console for RabbitMQ, Azure Service Bus, MSMQ, and ActiveMQ.**](https://www.cogin.com/mq/)
With QueueExplorer you can see what happens in your queues, edit and fix problematic messages, extract business data from JSON or XML payloads,
or send thousands of messages for stress testing.

And by [**Rebus Pro.**](https://pro.rebus.fm)
Rebus is a free .NET "service bus", and [**Rebus Pro is the perfect one-up for serious Rebus users.**](https://pro.rebus.fm)
Use Fleet Manager to get Slack alerts when something fails and retry dead-lettered messages with a click of the mouse.

</Sponsorships>

Designing long-lived processes in a distributed environment is an interesting engineering challenge.

And a well known pattern for solving this problem is a [**Saga**](https://microservices.io/patterns/data/saga.html).

A **Saga** is a sequence of local transactions, where each local transaction updates the **Saga** state and publishes a message triggering the next step in the **Saga**.

Sagas come in two forms:

- **Orchestrated**
- **Choreographed**

With an orchestrated Saga, there's a central component responsible for orchestrating the individual steps.

In a choreographed Saga, processes work independently but coordinate with each other using events.

In this week's issue, I'll show you how to create an **orchestrated Saga** using the **Rebus** library with **RabbitMQ** for message transport.

Let's dive in.

## Rebus Configuration

[Rebus](https://github.com/rebus-org/Rebus) is a free .NET “service bus”, and it's practical for implementing asynchronous messaging-based
communication between the components of an application.

Let's install the following libraries:

- `Rebus.ServiceProvider` for managing the **Rebus** instance
- `Rebus.RabbitMq` for **RabbitMQ** message transport
- `Rebus.SqlServer` for **SQL Server** state persistence

```powershell
Install-Package Rebus.ServiceProvider -Version 8.4.0
Install-Package Rebus.RabbitMq -Version 8.0.0
Install-Package Rebus.SqlServer -Version 7.3.1
```

Inside of your **ASP.NET Core** application you will need the following configuration.

```csharp
services.AddRebus(
    rebus => rebus
        .Routing(r =>
            r.TypeBased().MapAssemblyOf<Program>("newsletter-queue"))
        .Transport(t =>
            t.UseRabbitMq(
                configuration.GetConnectionString("RabbitMq"),
                inputQueueName: "newsletter-queue"))
        .Sagas(s =>
            s.StoreInSqlServer(
                configuration.GetConnectionString("SqlServer"),
                dataTableName: "Sagas",
                indexTableName: "SagaIndexes"))
        .Timeouts(t =>
            t.StoreInSqlServer(
                builder.Configuration.GetConnectionString("SqlServer"),
                tableName: "Timeouts"))
);

services.AutoRegisterHandlersFromAssemblyOf<Program>();
```

Unpacking the individual configuration steps:

- `Routing` - Configures messages to be routed by their type
- `Transport` - Configures the message transport mechanism
- `Sagas` - Configures the Saga persistence store
- `Timeouts` - Configures the timeouts persistence store

You also need to specify the queue name for sending and receiving messages.

`AutoRegisterHandlersFromAssemblyOf` will scan the specified assembly and automatically register the respective message handlers.

## Creating The Saga With Rebus

We're going to create a **Saga** for a newsletter onboarding process.

When a user subscribes to the newsletter we want to:

- Send a welcome email immediately
- Send a follow-up email after 7 days

The first step in creating the **Saga** is defining the data model by implementing `ISagaData`.
We'll keep it simple and store the `Email` for **correlation**, and add two flags for the distinct steps in our **Saga**.

```csharp
public class NewsletterOnboardingSagaData : ISagaData
{
    public Guid Id { get; set; }
    public int Revision { get; set; }

    public string Email { get; set; }

    public bool WelcomeEmailSent { get; set; }

    public bool FollowUpEmailSent { get; set; }
}
```

Now we can define the `NewsletterOnboardingSaga` class by inheriting from the `Saga` class and implementing the `CorrelateMessages` method.

It's a best practice to use a unique value for correlation.
In our case this will be the `Email`.

You also configure how the `Saga` starts with `IAmInitiatedBy`, and the individual messages the `Saga` handles with `IHandleMessages`.

```csharp
public class NewsletterOnboardingSaga :
    Saga<NewsletterOnboardingSagaData>,
    IAmInitiatedBy<SubscribeToNewsletter>,
    IHandleMessages<WelcomeEmailSent>,
    IHandleMessages<FollowUpEmailSent>
{
    private readonly IBus _bus;

    public NewsletterOnboardingSaga(IBus bus)
    {
        _bus = bus;
    }

    protected override void CorrelateMessages(
        ICorrelationConfig<NewsletterOnboardingSagaData> config)
    {
        config.Correlate<SubscribeToNewsletter>(m => m.Email, d => d.Email);

        config.Correlate<WelcomeEmailSent>(m => m.Email, d => d.Email);

        config.Correlate<FollowUpEmailSent>(m => m.Email, d => d.Email);
    }

    /* Handlers omitted for brevity */
}
```

## Message Types And Naming Conventions

There are two types of messages you send in a **Saga**:

- Commands
- Events

Commands instruct the receiving component what to do.\
Think: **verb, imperative.**

Events notify the Saga which process was just completed.\
Think: **what happened, past tense.**

## Saga Orchestration With Messages

The `NewsletterOnboardingSaga` starts by handling the `SubscribeToNewsletter` command, and publishes a `SendWelcomeEmail` command.

```csharp
public async Task Handle(SubscribeToNewsletter message)
{
    if (!IsNew)
    {
        return;
    }

    await _bus.Send(new SendWelcomeEmail(message.Email));
}
```

The `SendWelcomeEmail` command is handled by a different component, which publishes a `WelcomeEmailSent` event when it completes.

In the `WelcomeEmailSent` handler we update the `Saga` state and publish a **deferred message** by calling `Defer`.
Rebus will persist the `SendFollowUpEmail` command, and publish it when the **timeout expires**.

```csharp
public async Task Handle(WelcomeEmailSent message)
{
    Data.WelcomeEmailSent = true;

    await _bus.Defer(TimeSpan.FromDays(3), new SendFollowUpEmail(message.Email));
}
```

Finally, the `SendFollowUpEmail` command is handled and we publish the `FollowUpEmailSent` event.

We update the `Saga` state again, and also call `MarkAsComplete` to complete the `Saga`.

```csharp
public Task Handle(FollowUpEmailSent message)
{
    Data.FollowUpEmailSent = true;

    MarkAsComplete();

    return Task.CompletedTask;
}
```

Completing the `Saga` will delete it from the database.

## Handling Commands With Rebus

Here's how the `SendWelcomeEmail` command handler looks like.

```csharp
public class SendWelcomeEmailHandler : IHandleMessages<SendWelcomeEmail>
{
    private readonly IEmailService _emailService;
    private readonly IBus _bus;

    public SendWelcomeEmailHandler(IEmailService emailService, IBus bus)
    {
        _emailService = emailService;
        _bus = bus;
    }

    public async Task Handle(SendWelcomeEmail message)
    {
        await _emailService.SendWelcomeEmailAsync(message.Email);

        await _bus.Reply(new WelcomeEmailSent(message.Email));
    }
}
```

The important thing to highlight here is that we're using the `Reply` method to send a message back.
This will reply back to the endpoint specified as the return address on the current message.

## In Summary

**Sagas** are practical for implementing a long-lived process in a distributed system.
Each business process is represented by a local transaction, and publishes a message to trigger the next step in the **Saga**.

Although **Sagas** are very powerful, they are also _complicated to develop, maintain and debug._

We didn't cover a few important topics in this newsletter:

- Error handling
- Message retries
- Compensating transactions

I think you'll have some fun researching these on your own.

Take a look at the [**source code for the example used in this newsletter**](https://github.com/m-jovanovic/newsletter-orchestrated-saga)
if you want to learn more about implementing Sagas.

If you have **Docker** installed, you should be able to run it without a problem and try it out.

Thank you for reading, and have an awesome Saturday.

---



<Sponsorships>

This week's issue is sponsored by [**Rebus Pro.**](https://pro.rebus.fm)
Rebus Pro is the perfect one-up for serious Rebus users - use Fleet Manager to get Slack alerts when something fails,
and [**retry dead-lettered messages with a click of the mouse.**](https://pro.rebus.fm)

And by [**Uno Platform**](https://platform.uno/docs/articles/get-started-vs-2022.html?utm_source=MilanJovanovic&utm_medium=newsletter&utm_campaign=GetStarted).
Uno Platfrom is a free and open-source development platform that allows you to build single codebase applications for Windows, iOS, Android, WebAssembly,
macOS, and Linux with C# and XAML.
[**Easily create applications that look and feel native**](https://platform.uno/docs/articles/get-started-vs-2022.html?utm_source=MilanJovanovic&utm_medium=newsletter&utm_campaign=GetStarted)
to each platform without having to rewrite your codebase from scratch.

</Sponsorships>

**MediatR** is a popular library with a simple **mediator pattern** implementation in .NET.

Here's a definiton taken from MediatR's GitHub: **"In-process messaging with no dependencies."**

With the rise in popularity of the **CQRS pattern**, MediatR became the go-to library to implement commands and queries.

However, MediatR also has support for the **publish-subscribe** pattern using notifications.
You can publish an `INotification` instance and have multiple subscribers handle the published message.

Until recently, the handlers subscribing to an `INotification` message could only execute serially, one by one.

In this week's newsletter, I'll show you how to configure MediatR to **execute the handlers in parallel**.

Let's dive in.

## How Publish-Subscribe Works With MediatR

Before I talk about notification publishing strategies, let's see how **publish-subscribe** works with **MediatR**.

You need a class implementing the `INotification` interface:

```csharp
public record OrderCreated(Guid OrderId) : INotification;
```

Then you need a respective `INotificationHandler` implementation:

```csharp
public class OrderCreatedHandler : INotificationHandler<OrderCreated>
{
    private readonly INotificationService _notificationService;

    public OrderCreatedHandler(INotificationService notificationService)
    {
        _notificationService = notificationService;
    }

    public async Task Handle(
        OrderCreated notification,
        CancellationToken cancellationToken)
    {
        await _notificationService.SendOrderCreatedEmail(
            notification.OrderId,
            cancellationToken);
    }
}
```

And then you simply publish a message using either `IMediator` or `IPublisher`.
I prefer using the `IPublisher` because it's more expressive:

```csharp
await publisher.Publish(new OrderCreated(order.Id), cancellationToken);
```

MediatR will invoke all the respective handlers.

## Introducing Notification Publisher Strategies

Before MediatR v12, the publishing strategy would invoke each handler individually.

However, there's a new interface `INotificationPublisher` controlling how the handlers are called.

The default implementation of this interface is `ForeachAwaitPublisher`:

```csharp
public class ForeachAwaitPublisher : INotificationPublisher
{
    public async Task Publish(
        IEnumerable<NotificationHandlerExecutor> handlerExecutors,
        INotification notification,
        CancellationToken cancellationToken)
    {
        foreach (var handler in handlerExecutors)
        {
            await handler
                .HandlerCallback(notification, cancellationToken)
                .ConfigureAwait(false);
        }
    }
}
```

But now you can also use the `TaskWhenAllPublisher`:

```csharp
public class TaskWhenAllPublisher : INotificationPublisher
{
    public Task Publish(
        IEnumerable<NotificationHandlerExecutor> handlerExecutors,
        INotification notification,
        CancellationToken cancellationToken)
    {
        var tasks = handlerExecutors
            .Select(handler => handler.HandlerCallback(
                notification,
                cancellationToken))
            .ToArray();

        return Task.WhenAll(tasks);
    }
}
```

Here's a comparison between these two strategies.

`ForeachAwaitPublisher`:

- Invokes each handler one by one
- Fails when an exception occurs in one of the handlers

`TaskWhenAllPublisher`:

- Invokes all the handlers at the same time
- Executes all the handlers regardless of one of them throwing an exception

If you store the task returned by `TaskWhenAllPublisher` you can access the `Task.Exception` property, which will contain an `AggregateException` instance.
You can then implement more robust exception handling.

## Configuring MediatR Notification Publishing Strategy

How do we configure which `INotificationPublisher` strategy MediatR will use?

There's a new way to apply configuration options when calling the `AddMediatR` method.

You supply an `Action<MediatRServiceConfiguration>` delegate and configure the `MediatRServiceConfiguration` instance.

If you want to use the `TaskWhenAllPublisher` strategy, you can either:

- Provide a value for the `NotificationPublisher` property
- Specify the strategy type on the `NotificationPublisherType` property

```csharp
services.AddMediatR(config => {
    config.RegisterServicesFromAssemblyContaining<Program>();

    // Setting the publisher directly will make the instance a Singleton.
    config.NotificationPublisher = new TaskWhenAllPublisher();

    // Seting the publisher type will:
    // 1. Override the value set on NotificationPublisher
    // 2. Use the service lifetime from the ServiceLifetime property below
    config.NotificationPublisherType = typeof(TaskWhenAllPublisher);

    config.ServiceLifetime = ServiceLifetime.Transient;
});
```

You can also implement a custom `INotificationPublisher` instance and use your own implementation instead.

## How Is This Useful?

Being able to **run notification handlers in parallel** provides a significant **performance improvement** over the default behavior.

However, note that all handlers will use the same service scope.

If you have service instances that don't support concurrent access you may run into problems.

Unfortunately, one such service instance is the **EF Core** `DbContext`.

In any case, I think this is a great addition to the already amazing **MediatR** library.

That's all for today.

See you next week.

---



<Sponsorships>

This week's issue is sponsored by [**Localizely.**](https://localizely.com/?utm_source=milanjovanovic.tech&utm_medium=email&utm_campaign=website2)
Localizely is the translation management platform that helps you translate texts in your app for targeting multilingual markets.
With Localizely you can collaborate with your team on translations, and reduce translation errors with better context and app screenshots.
[**Learn more here.**](https://localizely.com/?utm_source=milanjovanovic.tech&utm_medium=email&utm_campaign=website2)

And by [**QA Wolf.**](https://www.qawolf.com/lp/qa-as-a-service?utm_campaign=QAWolfGetsYouTo80Percent03042023&utm_source=milannetweekly&utm_medium=newsletter)
QA Wolf gets you to 80% automated end-to-end test coverage in 4 months - and keeps you there.
They will build, run and maintain your test suite so that you don't have to.
[**Chat with QA Wolf.**](https://www.qawolf.com/lp/qa-as-a-service?utm_campaign=QAWolfGetsYouTo80Percent03042023&utm_source=milannetweekly&utm_medium=newsletter)

</Sponsorships>

**Data-driven testing** is a testing method where test data is provided through some external source.
Hence it's also known as **parameterized testing**.

A popular testing library in .NET that supports parameterized testing is **xUnit**.
It uses attributes to define test methods.
The `Fact` attribute defines a simple test, and the `Theory` attribute defines a parameterized test.

In this week's newsletter, I'm going to show you four ways to write **parameterized tests** with xUnit:

- `InlineData`
- `MemberData`
- `ClassData`
- `TheoryData`

And I'll discuss which approach I think is the best.

Let's dive in.

## Writing Parameterized Tests With InlineData

The simplest way to write parameterized tests with xUnit is using the `InlineData` attribute.
You provide test data by passing in values to the `InlineData` constructor.

Here's how that would look like:

```csharp
[Theory]
[InlineData("test@test.com", "test.com")]
[InlineData("milan@milanjovanovic.tech", "milanjovanovic.tech")]
public void EmailParser_Should_Return_Domain(string email, string expectedDomain)
{
    // Arrange
    var parser = new EmailParser();

    // Act
    var domain = parser.ParseDomain(email);

    // Assert
    Assert.Equal(domain, expectedDomain);
}
```

In this example, we provide two `string` values to the `InlineData` attribute, which represent the `email` and `expectedDomain` parameters in the test.
We can specify the `InlineData` attribute as many times as we want, to introduce more test cases.

The downside of this approach is that it becomes very verbose when we have many test cases.
And we are limited to only using constant data for the parameters.

## Writing Parameterized Tests With MemberData

With the `MemberData` attribute we have the ability to programmatically provide the test data.
You can load the test data from a static property or member of a type.

Here's an example of using the `MemberData` attribute to load test data from a property:

```csharp
[Theory]
[MemberData(nameof(EmailTestData))]
public void EmailParser_Should_Return_Domain(string email, string expectedDomain)
{
    // Arrange
    var parser = new EmailParser();

    // Act
    var domain = parser.ParseDomain(email);

    // Assert
    Assert.Equal(domain, expectedDomain);
}

public static IEnumerable<object[]> EmailTestData => new List<object>
{
    new object[] { "test@test.com", "test.com" },
    new object[] { "milan@milanjovanovic.tech", "milanjovanovic.tech" }
};
```

You specify the name of the member in the `MemberData` attribute, and it's a best practice to use the `nameof` operator
so that you can rename the property (or method) in the future without breaking your test.

The one constraint is that the property (or method) has to return `IEnumerable<object[]>`, so there is no strong typing.

## Writing Parameterized Tests With ClassData

The `ClassData` attribute allows you to extract test data into its own class.
This is helpful for organizing your test data separately from your tests, and it allows for easier reuse.
You load the test from a class the inherits from `IEnumerable<object[]>` and implements the `GetEnumerator` method.

Here's an example of using the `ClassData` attribute to load test data from a class:

```csharp
[Theory]
[ClassData(typeof(EmailTestData))]
public void EmailParser_Should_Return_Domain(string email, string expectedDomain)
{
    // Arrange
    var parser = new EmailParser();

    // Act
    var domain = parser.ParseDomain(email);

    // Assert
    Assert.Equal(domain, expectedDomain);
}

public class EmailTestData : IEnumerable<object[]>
{

    public IEnumerable<object[]> GetEnumerator()
    {
        yield return new object[] { "test@test.com", "test.com" };
        yield return new object[] { "milan@milanjovanovic.tech", "milanjovanovic.tech" };
    }

    IEnumerator IEnumerable.GetEnumerator() => GetEnumerator();
};
```

Unfortunately, this approach is complicated because you have to implement the `IEnumerable` interface.

It almost defeats the purpose of separating test data from the actual tests.

And we still suffer from lack of type-safety.

Is there a better solution?

## Writing Parameterized Tests With TheoryData

Let me introduce you to `TheoryData`, which is my preferred way of providing test data for parameterized tests.
Using the `TheoryData` class you can implement a class to provide test data while having the benefit of type-safety.

Here's an example of using `TheoryData` in combination with `ClassData`:

```csharp
[Theory]
[ClassData(typeof(EmailTestData))]
public void EmailParser_Should_Return_Domain(string email, string expectedDomain)
{
    // Arrange
    var parser = new EmailParser();

    // Act
    var domain = parser.ParseDomain(email);

    // Assert
    Assert.Equal(domain, expectedDomain);
}

public class EmailTestData : TheoryData<string, string>
{
    public EmailTestData()
    {
        Add("test@test.com", "test.com");
        Add("milan@milanjovanovic.tech", "milanjovanovic.tech");
    }
};
```

How does `TheoryData` work?

It's a generic class that allows us to specify the types for our parameterized test.

You just call the `Add` method in the `EmailTestData` constructor to provide test data for a single test case.
And introducing more test cases comes down to calling the `Add` method multiple times.

You can also use `TheoryData` in combination with `MemberData`, and return `TheoryData` from a property or method.

## Which Approach Should You Use?

I showed you four approaches to write parameterized tests with xUnit:

- `InlineData`
- `MemberData`
- `ClassData`
- `TheoryData`

So which one should you use?

Here's my personal preference that you can follow if you want:

- `InlineData` for simple test cases
- `TheoryData` using `ClassData` for complex test cases

Thank you for reading, and have a wonderful Saturday.

---



<Sponsorships>

Today's issue is sponsored by [**Hasura**](https://hasura.io/graphql/database/sql-server/?utm_source=newsletter&utm_medium=email&utm_campaign=milan-dotnet-weekly),
an open-source engine that gives
[**instant GraphQL and REST APIs on new or existing SQL Server**](https://hasura.io/graphql/database/sql-server/?utm_source=newsletter&utm_medium=email&utm_campaign=milan-dotnet-weekly),
enabling teams to ship apps faster.

And by [**Localizely**](https://localizely.com/?utm_source=milanjovanovic.tech&utm_medium=email&utm_campaign=website2),
the translation management platform that helps you
[**translate texts in your app for targeting multilingual markets.**](https://localizely.com/?utm_source=milanjovanovic.tech&utm_medium=email&utm_campaign=website2)

</Sponsorships>

**Entity Framework Core (EF Core)** is a popular ORM in .NET that allows you to work with SQL databases.
EF Core uses a `DbContext`, which represents a session with the database and is responsible for tracking changes,
performing database operations, and managing database connections.

It's common to have only one `DbContext` for the entire application.

But what if you need to have **multiple DbContexts**?

In this week's newsletter we're going to explore:

- When you may want to use multiple DbContexts
- How to create multiple DbContexts
- What are the benefits of using multiple DbContexts

Let's dive in!

## Why Use Multiple DbContexts?

There are a few cases where using **multiple DbContexts can be useful.**

**Multiple Databases**\
Does your application need to work with multiple SQL databases?
Then you're forced to use multiple DbContexts, each one dedicated to a specific SQL database.

**Separating Concerns**\
If the application you're building has a complex domain model, you may see an improvement by separating concerns
between a few DbContexts, where each one is responsible for a specific area of the domain model.

**Modular Monolith**\
When you're building a **Modular Monolith**, using multiple DbContexts can be practical because you can configure
a different **database schema** per `DbContext`, giving you logical separation at the database level.

**Read Replicas**\
You can configure a separate `DbContext` instance to access the read replica of your database, and use that
`DbContext` for read-only queries.
You can also configure `QueryTrackingBehavior.NoTracking` on the `DbContext` level to improve query performance.

## Creating Multiple DbContexts In a Single Application

Here's how you can easily configure multiple DbContexts.
Let's say we have a `CatalogDbContext` and an `OrderDbContext` in our application.
We want to configure them using the following constrainsts:

- Both DbContexts use the **same database**
- Each DbContext has a **separate database schema**

```csharp
public class CatalogDbContext : DbContext
{
    public DbSet<Product> Products { get; set; }

    public DbSet<Category> Categories { get; set; }
}

public class OrderDbContext : DbContext
{
    public DbSet<Order> Orders { get; set; }

    public DbSet<LineItem> LineItems { get; set; }
}
```

First we need to configure the `CatalogDbContext` and `OrderDbContext` with the DI container.
You can do this by calling the `AddDbContext` method and specifying which `DbContext` is being configured,
and then using the SQL provider specific method to pass the connection string.
In this case I'm connecting to SQL Server with the `UseSqlServer` method.

```csharp
using Microsoft.EntityFrameworkCore;

services.AddDbContext<CatalogDbContext>(options =>
    options.UseSqlServer("CONNECTION_STRING"));

services.AddDbContext<OrderDbContext>(options =>
    options.UseSqlServer("CONNECTION_STRING"));
```

If you just want to use both DbContexts in the same schema, then this is all the configuration you need.
You can now inject the `DbContext` instances in your application and use them.

However, if you want to configure a different schema for each `DbContext` then you also need to override
the `OnModelCreating` method and specify the custom schema with `HasDefaultSchema`.

```csharp
public class CatalogDbContext : DbContext
{
    public DbSet<Product> Products { get; set; }

    public DbSet<Category> Categories { get; set; }

    protected override void OnModelCreating(ModelBuilder modelBuilder)
    {
        modelBuilder.HasDefaultSchema("catalog");
    }
}

public class OrderDbContext : DbContext
{
    public DbSet<Order> Orders { get; set; }

    public DbSet<LineItem> LineItems { get; set; }

    protected override void OnModelCreating(ModelBuilder modelBuilder)
    {
        modelBuilder.HasDefaultSchema("order");
    }
}
```

Limitations with multiple DbContexts:

1. It's not possible to do a join between different `DbContext` instances, because **EF Core** doesn't know if they
   are using the same database
2. Transactions will only work if the DbContexts are using the same database. You have to create a new transaction
   and share it between the DbContexts by [calling the `UseTransaction` method](/blog/working-with-transactions-in-ef-core#using-existing-transactions-with-ef-core)

**Migrations History Table**

If you decide to use different schemas per `DbContext`, you will be unpleasantly surprised to learn
that the default schema doesn't apply to the migrations history table.

You need to configure this by calling the `MigrationsHistoryTable` method and specifying the table name
and schema where the migrations history for that context will live.
I used the `HistoryRepository.DefaultTableName` constant in this example, but you can specify a custom
table name if you want to.

```csharp
using Microsoft.EntityFrameworkCore;
using Microsoft.EntityFrameworkCore.Migrations;

services.AddDbContext<CatalogDbContext>(options =>
    options.UseSqlServer(
        "CONNECTION_STRING",
        o => o.MigrationsHistoryTable(
            tableName: HistoryRepository.DefaultTableName,
            schema: "catalog")));

services.AddDbContext<OrderDbContext>(options =>
    options.UseSqlServer(
        "CONNECTION_STRING",
        o => o.MigrationsHistoryTable(
            tableName: HistoryRepository.DefaultTableName,
            schema: "order")));
```

## Benefits Of Using Multiple DbContexts

Using multiple DbContexts can offer several benefits to your application:

- Separation of concerns
- Better performance
- More control & security

Each DbContext can be responsible for a specific subset of the application's data, which can help organize the code
and make it more modular.

When you separate data access into multiple DbContexts, the application can reduce the risk of contention and improve
concurrency, and this can improve performance.

And if you're using multiple DbContexts, you can configure more granular access control to improve application security.
You can also optimize performance and resource usage.

## In Summary

Using **multiple EF Core DbContexts** in a single application is straightforward and has many benefits.

For ready-heavy applications you can configure a separate `DbContext` to turn off query tracking by default
and get improved performance.

Also, using multiple DbContexts is practical if you're building a **Modular monolith**.
You can configure the DbContexts to be in **separate database schemas**, giving you logical separation at the database level.

That's all for today.

See you next week.

---


Previous issues of Milan's .NET Weekly
